Land Rover

Discovery Sport Hybrid Battery

2020-Present

Compact family hybrid battery service for Land Rover Discovery Sport PHEV (P300e) and MHEV models. Expert reconditioning and replacement with comprehensive warranty.

PHEV Model

P300e

MHEV System

48V Technology

Warranty

6-24 Months

Family

5+2 Seater

Get Free Quote Call Us

Sport

Compact

Technical Specifications

Discovery Sport Battery Systems

Comprehensive battery specifications for Land Rover Discovery Sport PHEV and MHEV hybrid systems

Battery Type

Lithium-ion NCM

Voltage

~320-400V DC

Capacity

15 kWh (usable ~12 kWh)

Electric Range

Up to 62 km (WLTP)

Charging Time

7 kW: ~1.5 hours

Models

P300e variants

Common PHEV Battery Issues

P0A1F-49 Code: Battery Energy Control Module (BECM) internal failure - memory corruption or processor fatigue on BECM board. Requires BECM replacement (LR137929/LR175174), not entire battery pack. BECM is VIN-locked and requires TOPIx Cloud "Replace ECU" routine for pairing.
P0AA0-66 Code: HV battery contactor circuit fault causing "Charging System Fault" - often related to CSC (Cell Supervision Circuit) board failures or contactor welding
P0B3C/P0B3F Codes: Cell Supervision Circuit (CSC) board failure showing erratic voltage readings. Modular CSC boards can be replaced individually without full pack replacement.
Charging Issues: Intermittent charging due to contactor failures, HV coolant pump failure (LR059341), or auxiliary 12V battery (LR132266) preventing "Ready" mode
Dead Battery Revival: Battery below contactor threshold requires "bootstrapping" - BSU at 13.5V/100A + TOPIx "Rescue Charge" to force contactors closed

Professional JLR Diagnostic Equipment

We use official Jaguar Land Rover diagnostic tools for accurate diagnosis and programming:

TOPIx Cloud

Official JLR diagnostic system

Pathfinder

Technical repair information

SDD (IDS)

Symptom Driven Diagnostics

Certified Techs

JLR-trained specialists
