Land Rover

Range Rover Velar Hybrid Battery

2021-Present

Sophisticated hybrid battery service for Range Rover Velar PHEV (P400e) and MHEV models. Expert reconditioning with warranty coverage for this elegant mid-size luxury SUV.

PHEV Model

P400e

MHEV System

48V Technology

Warranty

6-24 Months

Elegant

Sleek Design

Get Free Quote Call Us

Velar

Elegant

Technical Specifications

Range Rover Velar Battery Systems

Comprehensive battery specifications for Land Rover Range Rover Velar PHEV and MHEV systems

Battery Type

Lithium-ion NCM

Voltage

~320-400V DC

Capacity

17.1 kWh (usable ~15 kWh)

Electric Range

Up to 53 km (WLTP)

Charging Time

7 kW: ~2 hours

Models

P400e variants

Common PHEV Battery Issues

P0A1F-49 Code: Battery Energy Control Module (BECM) internal failure - memory corruption or processor fatigue on BECM board. Requires BECM replacement (LR137929/LR175174), not entire battery pack. BECM is VIN-locked and requires TOPIx Cloud "Replace ECU" routine for pairing.
P0AA0-66 Code: HV battery contactor circuit fault causing "Charging System Fault" - often related to CSC (Cell Supervision Circuit) board failures or contactor welding
P0B3C/P0B3F Codes: Cell Supervision Circuit (CSC) board failure showing erratic voltage readings. Modular CSC boards can be replaced individually without full pack replacement.
Charging Issues: Intermittent charging due to contactor failures, HV coolant pump failure (LR059341), or auxiliary 12V battery (LR132266) preventing "Ready" mode
Dead Battery Revival: Battery below contactor threshold requires "bootstrapping" - BSU at 13.5V/100A + TOPIx "Rescue Charge" to force contactors closed

Professional JLR Diagnostic Equipment

Official Jaguar Land Rover diagnostic tools:

TOPIx Cloud

Official JLR diagnostic

Pathfinder

Technical repair info

SDD (IDS)

Symptom Diagnostics

Certified Techs

JLR specialists

Our Service Process
